Fork
FOX FLOAT 36 Factory, GRIP2 damper, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel
Rear Shock
FOX FLOAT X2 Factory, Rx Trail Tune, 2-position open/firm lever, HSC, LSC, HSR, and LSR adjustment, S1:210x50mm, S2-S6:210x55mm "
Seat Binder
Alloy, 38.6mm
Frame
FACT 11m carbon chassis and rear-end, asymmetrical design, 29/27.5 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel
Saddle
Bridge, 155/143mm, Hollow Ti-rails
Grips
Deity Lockjaw
Stem
Deity, 35.0mm
Handlebars
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm
SeatPost
Bike Yoke, Revive Max, 34.9 (S1:120mm, S2/S3:160mm, S4/S5: 185mm, S6:213mm)
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5 x 2.3"
Inner Tubes
Standard, Presta
Rear Hub
DT Swiss 350, 32h, 12x148
Spokes
DT Swiss Competition Race
Rims
Roval Traverse 29 HD Carbon, 30mm internal width, 28h: Roval Traverse 27.5 HD Carbon, 30mm internal width, 32h
Front Hub
DT Swiss 350, 28h, 15x110
Shift Levers
SRAM AXS POD Controller
Bottom Bracket
SRAM DUB WIDE, BSA 73mm, Threaded
Crankset
SRAM X0 Eagle, with Aluminum Guards, DUB, 32T, S1:165mm, S2-S5: 170mm, S6: 175mm
Chain
SRAM X0 Eagle Transmission Flattop Chain, 12spd
Rear Derailleur
SRAM X0 Eagle Transmission Derailleur
Cassette
SRAM X0 Eagle Transmission Cassette, 12spd, 10-52T
Chainrings
32T
Front Brake
SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
Rear Brake
SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
Weight
14.5kg (31lb, 15.5oz)
Weight Size
S4
