Levo 4 EVO is built for riders who don’t tiptoe around terrain. The riders who point into the steep stuff, ride bike parks without a chairlift, and want a bike that stays calm when things get fast, rough, and consequential. This is Electric All Mountain
Â
Use
Electric All Mountain
E-System
Specialized 3.1 Motor w/ 810 Watts & 105 Nm, 840 Wh Battery, up to 5 hour range w/ optional Range Extender
Frame
Levo EVO FACT 11m carbon frame, Geo Adj & SWAT Storage
Suspension
Fork: 180mm RockShox Zeb Select
Shock: Vivid Select Air Linear
Drivetrain
SRAM S1000 Eagle AXS
Wheels
Specialized Alloy Wheels
Â
Motor
Specialized 3.1 Motor, 105Nm torque, 810W power
Battery
840Wh battery
UI/Remote
Mastermind TCU, 2.2" high resolution screen, fully customizeable with Specialized app, works with Apple Find My
Charger
Specialized 4amp charger
Frame
Levo Evo FACT 11m carbon frame, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm rear travel, 29" front wheel/27.5" rear wheel, adjustable head tube angle, chainstay length, integrated SWAT storage
Seat Binder
Alloy, 38.6mm
Rear Shock
All New Vivid Select air, 230x62.5mm, Linear XL spring, RT damper w/climb switch, rebound adjust
Fork
All New SRAM FS ZEB Select, 29" 180mm, Linear XL spring, Delta RC damper, rebound adjust
Front Brake
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor
Rear Brake
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor
Shift Levers
SRAM AXS Pod Controller w/discrete clamp
Rear Derailleur
SRAM S1000 Eagle AXS
Cassette
SRAM 12-speed,10-52t
Chain
SRAM GX Eagle Transmission 12-Speed Flattop Chain
Crankset
SRAM S1000 Alloy crank, ISIS interface, 155mm length
Chainrings
SRAM 34t T-Type chainring, 104 BCD, steel
Rims
Specialized Alloy Rims
Front Hub
Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 28h
Rear Hub
Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 32h, HG Steel Fhb
Spokes
DT Swiss Elemental
Front Tire
Butcher, GRID Gravity, T9, TLR, 29x2.4"
Rear Tire
Cannibal GRID Gravity T9 TLR Downhill Tire 27.5x2.4"
Inner Tubes
Standard, Presta Valve
Stem
Alloy Trail Stem, 35mm bar bore
Handlebars
Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise
Grips
Specialized Trail Grips
Saddle
Bridge Comp, Hollow Cr-mo rails 155/143
SeatPost
Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
SWAT
SWAT Internal downtube storage
Weight
25.16 kg (55 lb, 7.5 oz)
Weight Size
S4
